SRGZ8 Intel Xeon Gold 6240R 24-Core 2.40GHz 35.75MB 165W FCLGA3647 Processor
$630.00
- Brand: Intel
- Product Code: SRGZ8
- Availability: In Stock
Thanks For Contacting Us. Our sales team will get back soon to you!
×
Product Description
Intel Xeon Gold 6240R 24-Core 2.40GHz 35.75MB 165W FCLGA3647 Processor
Highlighted Features
- Intel Xeon Gold
- 6240R
- 24 Core
- 2.40GHz
- 35.75MB
- 165W
- FCLGA3647
- Processor
- Retail Part #: SRGZ8
Note: All product details are provided by Intel Corporation.
The Intel Xeon Gold 6240R is 24 Core Processor. This Intel Xeon part using the Cascade Lake architecture with Socket 3647. Intel Xeon Gold 6240R has 35.75MB of L3 cache and operates at 2.40GHz by default, but can boost up to 3.90GHz, depending on the workload.
Specification | |
| Brand: | Intel |
| Processor Number: | 6240R |
| Series: | Intel Xeon Gold |
| Code Name: | Cascade Lake |
| Product Type: | Processor |
| Number of Cores: | 24 |
| Lithography: | 14 nm |
| Base Frequency: | 2.40GHz |
| Max Turbo Frequency: | 4.00GHZ |
| Cache: | 35.75 MB |
| Bus Speed: | 10.4 GT/s |
| Number of Threads: | 48 |
| Max # of QPI Links: | 3 |
| TDP: | 165 W |
| Sockets Supported: | FCLGA3647 |
| Memory & Core Details | |
| Max Memory Size: | 1TB |
| Memory Types: | DDR4-2933 |
| Maximum Memory Speed: | 2933 MHz |
| Max Memory Channels: | 6 |
| ECC Memory Supported: | Yes |
| Technologies Supported | |
| Intel® Optane™ Persistent Memory Supported: | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost): | Yes |
| Intel® Resource Director Technology (Intel® RDT): | Yes |
| Intel® Speed Shift Technology: | Yes |
| Intel® Speed Select Technology - Base Frequency: | No |
| Intel® Turbo Boost Technology: | 2.0 |
| Thermal Monitoring Technologies: | Yes |
| Instruction Set: | 64-bit |
| Intel® Hyper-Threading Technology: | Yes |
| Intel® Transactional Synchronization Extensions: | Yes |
| Intel® 64: | Yes |
| Enhanced Intel SpeedStep® Technology: | Yes |
| # of AVX-512 FMA Units: | 2 |
| Instruction Set Extensions: | Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512 |
| Intel® Volume Management Device (VMD): | Yes |
| Intel® Resource Director Technology: | Yes |
Dimensions Specifications | |
| Dimension: | 10 x 8 x 4 in |
| Weight: | 1 lb |
