Dell PERC H330 Mini Mono 12GBps SAS/SATA Raid Controller
Highlighted Features
Dell
H330
Mini Mono
PCI-Express 3.0 x8
SAS/SATA
Controller Card
Retail Part #: GDJ3J
Optional Part #: 0GDJ3J
Note: All product details are provided by Dell
The PERC H330 entry-level controller card offers a straightforward solution that includes essential RAID levels and support for non-RAID (passthrough) configuration options. In addition - the card connects to SATA and SAS hard disk drives - and solid state drives - allowing for tiered storage that optimizes cost and performance. Physical disk power management technology provides additional cost savings by managing power consumption for idle - unconfigured and configured drives. Dell's entry-level RAID controllers cover the spectrum of tiered storage requirements for cost-sensitive applications that require robust data protection.
Controller Card Specification
Brand:
Dell
Product Type:
RAID Controller
Interface:
SATA 6Gps/SAS 12Gps
Data Transfer Rate:
1.2GB/s
Cache:
2GB
Form Factor:
MINI MONO
Devices Supported:
32
Ports:
Eight Port 8P
RAID Level:
RAID 0 1 5 6 10 50
Device Type:
Storage Controller (raid) - Plug-in Card
Max Operating Temperature:
0°C to 55°C
Dimensions
Dimensions:
10 x 8 x 4
Weight:
2 lb
Compatibility
PowerEdge R230
PowerEdge R230XL
PowerEdge R330
PowerEdge R330XL
PowerEdge R430
PowerEdge R530
PowerEdge R530XD
PowerEdge R630
PowerEdge R730
PowerEdge T130
PowerEdge T330
PowerEdge T430
×
